| Machine Dimension – L x W x H (mm) | 1,671 × 690 × 1153 |
| Operating Weight – (kg) › Diesel | 395 |
| Plate Size – L x W (mm) | 900 × 500 (Extended 900 × 690) |
| Centrifugal Force – kgf (kN) | 5,099 (50) |
| Vibration Frequency – Hz (vpm) | 70 (4,200) |
| Compaction Area – (m²/h) | 912 |
| Maximum Gradeability – (°) | 30 |
| Maximum Working Speed – (m/min) | 26 |
| Engine Options | HATZ® 1B40 @ 7.3kW (9.3hp) 4-Stroke Diesel (Recoil & Electric-Start) |
