| Machine Dimension – L x W x H (mm) | 1,239 × 600 × 1,112 |
| Operating Weight – (kg) › Diesel | 197 |
| Operating Weight – (kg) › Petrol | 183 |
| Plate Size – L x W (mm) | 700 × 600 |
| Centrifugal Force – kgf (kN) | 3,059 (30) |
| Vibration Frequency – Hz (vpm) | 90 (5,400) |
| Compaction Area – (m²/h) | 759 |
| Maximum Gradeability – (°) | 30 |
| Maximum Working Speed – (m/min) | 23 |
| Engine Options | HATZ® 1B20 @ 3.5kW (4.6hp) 4-Stroke Diesel (Recoil & Electric-Start)HONDA® GX270 @ 6.3kW (8.5hp) 4-Stroke Petrol |
