| Machine Dimension – L x W x H (mm) | 1,494 × 640 × 1,218 |
| Operating Weight – (kg) › Diesel | 320 |
| Operating Weight – (kg) › Petrol | 300 |
| Plate Size – L x W (mm) | 800 × 470 (Extended 800 × 640) |
| Centrifugal Force – kgf (kN) | 4,078 (40) |
| Vibration Frequency – Hz (vpm) | 70 (4,200) |
| Compaction Area – (m²/h) | 792 |
| Maximum Gradeability – (°) | 30 |
| Maximum Working Speed – (m/min) | 22 |
| Engine Options | HATZ® 1B30 @ 5.4kW (7.3hp) 4-Stroke Diesel (Recoil & Electric-Start)HONDA® GX270 @ 6.3kW (8.5hp) 4-Stroke Petrol |
