| Machine Dimension – L x W x H (mm) | 1,207 × 500 × 1,118 |
| Operating Weight – (kg) › Diesel | 155 |
| Operating Weight – (kg) › Petrol | 138 |
| Plate Size – L x W (mm) | 650 × 500 |
| Centrifugal Force – kgf (kN) | 3,059 (30) |
| Vibration Frequency – Hz (vpm) | 90 (5,400) |
| Compaction Area – (m²/h) | 650 |
| Maximum Gradeability – (°) | 25 |
| Maximum Working Speed – (m/min) | 22 |
| Water Tank Capacity – (litre) | 26 |
| Engine Options | HATZ® 1B20 @ 3.5kW (4.6hp) 4-Stroke Diesel (Recoil & Electric-Start)HONDA® GX160 @ 3.6kW (4.8hp) 4-Stroke Petrol |
