| Machine Dimension – L x W x H (mm) | 775 × 360 × 1,062 |
| Operating Weight – (kg) | 7270 (option)68 (option) |
| Shoe Size – L x W (mm) | 335 × 280335 × 230 (option)335 × 170 (option) |
| Stroke – (mm) | 80 |
| Impact Force – kgf (kN) | 1580 (15.5) |
| Blows per Minute | 650 - 700 |
| Compaction Depth – (mm) | 610 |
| Maximum Working Speed – (m/min) | 8-11 |
| Compaction Area – (m²/h) | 300 |
| Fuel Tank Capacity – (litre) | 3.5 |
| Engine Options | HONDA® GXE2.0S |
