| Machine Dimension – L x W x H (mm) | 775 × 360 × 1035 |
| Operating Weight – (kg) | 7068 (option)66 (option) |
| Shoe Size – L x W (mm) | 335 × 280335 × 230 (option)335 × 175 (option) |
| Stroke – (mm) | 50 - 80 |
| Impact Force – kgf (kN) | 1,600 (16) |
| Blows per Minute | 650 - 700 |
| Compaction Depth – (mm) | 610 |
| Maximum Working Speed – (m/min) | 10 |
| Compaction Area – (m²/h) | 260 |
| Fuel Tank Capacity – (litre) | 3.5 |
| Engine | hoppt® by DINKING ENGINE @ 2.9kW (4.0hp), 4-stroke petrol |
