• Specially-Designed TWIN-EXCITER System, creating a very powerful 22.0kn centrifugal force. • Powered by the German-made HATZ® 1 B40 Diesel Engines and the Durable Japan-made KUBOTA® EA330 Diesel Engines that complies with: • EPA Tier-4 Emissions Regulations Standard Exerting Durable Power with a Three Vortex Combustion System (TVCS), which provides Stable Performance even at high engine rpm and an ideal mixture of air and fuel to ensure low-fuel consumption. • Therefore, ensuring work goes smoothly and steadily. • In enclosed areas where petrol is restricted.
| Machine Dimension – L x W x H (mm) | 2,465 × 754 × 1,170 |
| Operating Weight – (kg) | 830 |
| Drum Size – D x W (mm) | 402 × 700 |
| Centrifugal Force – kgf (kN) | 2,243 (22.0) |
| Vibration Frequency – Hz (vpm) | 55 (3,300) |
| Maximum Working Speed – (km/h) | 3.6 |
| Gradeability – (°) | 25 |
| Water Tank Capacity – (litre) | 47 |
| Hydraulic Oil Capacity – (litre) | 30 |
| Engine Options | KUBOTA® EA330 @ 5.15kW (6.9hp) 4-Stroke Diesel (Electric-Start)HATZ® 1B40 @ 7.3kW (9.3hp) 4-Stroke Diesel (Recoil & Electric-Start) |
