Features and Benefits: • Two large Poclain hydraulic drive pumps and a vibration pump from Sauer Danfoss • Air-cooled HATZ diesel engine: powerful and environmentally friendly. • Hydrostatic drive and vibration system. • Hydrostatic adjustable excentric weights that are productive in both soil and asphalt applications. • Hydraulic pump for hydrostatic drive and steering: no V-belt or clutch. • Ergonomic vibration dampened operator handle, control panel with easy access. • Hydrostatic control lever and adjusting lever. • Two removable drum scrapers ensuring automatic cleaning. • MAXIMUM SAFETY: dead man safety button. • Hydraulic parking brake, reverse gear limited to 2.5 km/h. • Adjustable amplitude on asphalt (13 kN) as well as on soil (21 kN). • Anti corrosive oil tank.
| Weight – (kg) | 770 |
| Working Width – (mm) | 650 |
| Linear Charge – (kg/cm) | 5/28 |
| Drive | Hydrostatic |
| Diesel Engine | HATZ® 1B50 |
| Engine Power HP – (kW) | 11.3 (8.5) |
| Forward Speed – (km/h) | 4 |
| Speed Reverse Gear – (km/h) | 2.5 |
| Vibration | Hydrostatic |
| Centrifugal Force to Choose – (kN) | 13 / 21 |
| Vibration Motor Brand | Sauer Danfoss |
| Vibration Frequency Hz – (vpm) | 70 (3,300) |
| Gradeability With / Without Vibration – (%) | 25 / 45 |
| Water Tank Capacity – (litre) | 50 |
| Hydraulic Oil Tank – (litre) | 20 |
| Fuel Consumption – (litre/h) | 1.2 |
| Hour Meter | Option |
| Protective Cover | Yes |
| Compaction Depth* Big or Small Amplitude › Sand/Gravel – (cm) | 0/25 |
| Compaction Depth* Big or Small Amplitude › Usual Soil – (cm) | 20/15 |
| Note | *According to the nature of the soil – (kg/cm) |
