| Machine Dimension – L x W x H (mm) | 2,594 × 1,322 × 2,852 |
| Height – Top of the Steering Wheel – (mm) | 1,740 |
| Height – Top of ROPS – (mm) | 2,852 |
| Weight – (kg) | Operating Weight – 2,780Shipping Weight – 2,840 |
| Drum Weight – (kg) | Static Front – 686Static Rear – 686 |
| Drum Size – (mm) | Width (1,200) Option (1,000), Diameter (700), Shell Thickness (15)Side Clearance (50), Curb Clearance (648), Chamfered Edge Finishing |
| Drum Wiper Type | Spring-Loaded Self-Adjusting Steel Wiper |
| Vibration Frequency – Hz (vpm) | 66 (3,960) |
| Vibrating System | Nominal Amplitude 0.4Gear Pump – POCLAIN® Hydraulics, FRANCE |
| Vibrating Drums | Front/Both |
| Centrifugal Force – (kN) | 28 |
| Propulsion | DRUM DRIVE – Axial Piston Pump with Variable Displacement and2 Radial Piston Motors from POCLAIN® Hydraulics, FRANCE |
| Speed – (km/h) | 10 – Highest Speed |
| Brakes – Gradability (Theoretical) | 30°PARKING – SAHR (Spring-Applied Hydraulically Released) |
| Steering System and Design | 1 Cylinder, Double-Acting Hydraulic System with a Maintenance-Free Centre Pivot Articulation of ± 34°Outside Turning Radius – 3,600 mm |
| Water System | Pressurised Electric Diaphragm PumpFilters of 100 Mesh Screen @ Nozzle with 80 Mesh In-Line |
| Tank Capacity – (litre) | Water Tank – 205Fuel Tank – 50Hydraulic Tank – 68 |
