| Machine Dimension – L x W x H (mm) | 2,095 × 980 × 2,568 |
| Height – Top of the Steering Wheel (mm) | 1,534 |
| Height – Top of ROPS (mm) | 2,568 |
| Weight – (kg) | Operating Weight – 1,730Shipping Weight – 1,790 |
| Drum Weight – (kg) | Static Front – 376Static Rear – 376 |
| Drum Size – (mm) | Width (900) Option (1,000), Diameter (560), Shell Thickness (15)Side Clearance (40), Curb Clearance (337), Chamfered Edge Finishing |
| Drum Wiper Type | Spring-Loaded Self-Adjusting Steel Wiper |
| Vibration Frequency – Hz (vpm) | 66.7 (4,200) |
| Vibrating System | Nominal Amplitude 0.4Gear Pump – POCLAIN® Hydraulics, FRANCE |
| Vibrating Drums | Front/Both |
| Centrifugal Force – (kN) | 16 |
| Propulsion | DRUM DRIVE – Axial Piston Pump with Variable Displacement and2 Radial Piston Motors from POCLAIN® Hydraulics, FRANCE |
| Speed (km/h) | 10 – Highest Speed |
| Brakes – Gradability (Theoretical) | 35°PARKING – SAHR (Spring-Applied Hydraulically Released) |
| Steering System and Design | 1 Cylinder, Double-Acting Hydraulic System with a Maintenance-Free Centre Pivot Articulation of ± 30°Outside Turning Radius – 3,100 mm |
| Water System | Pressurised Electric Diaphragm PumpFilters of 100 Mesh Screen @ Nozzle with 80 Mesh In-Line |
| Tank Capacity – (litre) | Water Tank – 110Fuel Tank – 31Hydraulic Tank – 30 |
